Westfield IP67 Connectors & Cable Assemblies
IP67 M8 Male Straight 3,4,5,6,8 pin on Moulded Cable
Coding: A / B
Twist Lock
1M8MST Series
IP67 M8 Female Straight 3,4,5,6,8 pin on Moulded Cable Coding: A / B
Twist Lock
2M8FST Series
IP67 M8 Male Straight Shielded 3,4,5,6,8 pin on Moulded Cable
Coding: A / B
Twist Lock
3M8MSTS Series
IP67 M8 Female Straight Shielded 3,4,5,6,8 pin on Moulded Cable
Coding: A / B
Twist Lock
4M8FSTS Series
IP65 M8 Male Straight 3, 4 pin on Moulded Cable
Coding: A
Snap In Lock
5M8MSTSP Series
IP65 M8 Female Straight 3, 4 pin on Moulded Cable
Coding: A
Snap In Lock
6M8FSTSP Series
IP67 M8 Male Right Angle Shielded 3,4,5,6,8 pin on Moulded Cable
Coding: A / B
Twist Lock
9M8MRAS Series
IP67 M8 Female Right Angle 3,4,5,6,8 pin on Moulded Cable
Coding: A / B
Twist Lock
8M8FRA Series
IP65 M8 Male Right Angle 3,4,5,6,8 pin on Moulded Cable
Coding: A / B
Twist Lock
7M8MRA Series
IP65 M8 Male Right Angle 3,4,pin on Moulded Cable
Coding: A
Snap in Lock
11M8MRA Series
Tel: +44 (0) 1488 685183 email: sales@westfield.co.uk Fax: +44 (0) 1488 685430
IP65 and IP67 M8 Series for small sensors and actuators, Power or Data Applications: 3,4,5,6,8 Pin Types available, Some Shielded Options, Vibration Resistant Lock Screw Design, Ideally for Actuators and Sensors for Industrial Control Applications, Moulded Cable Types, Custom Cable Assemblies, 90 Degree Types, Red + Green LED Indication Type, Retro Field Fixing, Panel Mount Solder Bucket, PCB Mount, IP67 Dust-caps,
IP67 M8 Female with LED’S Right Angle 3,4,pin on Moulded Cable
Coding: A
Twist Lock
13M8FLEDRA Series
IP67 M8 Male Straight Field Install Solder Type 3,4,5 pin on Moulded Cable
Coding: A / B
Twist Lock
14M8MFI Series
IP67 M8 Female Straight Field Install Solder Type 3,4,5 pin on Moulded Cable
Coding: A / B
Twist Lock
15M8FFI Series
IP67 M8 Male Straight Front Panel Mount 3,4,5,6,8 pin Solder Bucket Contacts
Coding: A / B
Twist Lock
16M8MPMSC Series
IP67 M8 Female Straight Front Panel Mount 3,4,5,6,8 pin Solder Bucket Contacts
Coding: A / B
Twist Lock
19M8FPMSC Series
IP67 M8 Male Straight Rear Panel Mount 3,4,5,6,8 pin Solder Bucket Contacts
Coding: A / B
Twist Lock
18M8MPMSC Series
IP67 M8 Female Straight Rear Panel Mount 3,4,5,6,8 pin Solder Bucket Contacts
Coding: A / B
Twist Lock
17M8FPMSC Series
IP67 M8 Male Straight Front Panel Mount 3,4,pin Solder Bucket Contacts
Coding: A
Snap Lock
20M8MPMSC Series
IP67 M8 Male Straight Rear Panel Mount 3,4,pin Solder Bucket Contacts
Coding: A
Snap Lock
21M8MPMSC Series
IP67 M8 Male Straight Front Panel Mount 3,4,5,6,8 pin Straight PCB Contacts
Coding: A / B
Twist Lock
22M8MFPMPCB Series
IP67 M8 Female Straight Front Panel Mount 3,4,5,6,8 pin Straight PCB Contacts
Coding: A / B
Twist Lock
23M8FFPMPCB Series
IP67 M8 Male Straight Front Panel Mount 3,4,pin
Straight PCB Contacts
Coding: A
Snap Lock
24M8MFPMPCB Series
IP67 M8 Male to Female Straight Panel Mount Adaptor
4,5,6 pin
Coding: A / B
Twist Lock
25M8M2F Series
IP67 M8 Male Right Angle PCB Mount, Front Panel Mount 3,4,5, pin
Coding: A / B
Twist Lock
26M8MFPMPCB Series
IP67 M8 Female Right Angle PCB Mount, Front Panel Mount 3,4,5, pin
Coding: A / B
Twist Lock
27M8FFPMPCB Series
IP67 M8 Male Protection Caps to Prevent Water Ingress of Exposed Connectors
28M8MPC-1 Series
IP67 M8 Male and Female Protection Caps with Fixing Loop to Prevent Water Ingress of Exposed Connectors
30M8MPPC + 31M8FPPC
IP67 M8 Female Right Angle Shielded 3,4,5,6,8 pin on Moulded Cable
Coding: A / B
Twist Lock
10M8FRAS Series
IP65 M8 Female Right Angle 3,4,pin on Moulded Cable
Coding: A
Snap in Lock
12M8FRA Series
IP67 M8 Female Protection Caps to Prevent Water Ingress of Exposed Connectors
29M8FPC-1 Series
